Description
Fitted with the famous PZ drum mower keeping us in front of the competition. 42 years of proven reliability across the world. Robust build and proven reliability achieves outstanding outputs and first class cut in the heaviest crops. Flat sided drums are provide optimal grass transport to the GrassBox without risk of blockage. The rotating saucers have a major advantage in uneven ground. The saucers rotate over uneven ground rather than slide thus reducing pto power requirement while protecting stubble.
From the mower unit, the grass is lifted into the Grazer via a high capacity elevator that rotates at just 70rpm to avoid damaging the young grass, so ensuring maximum nutritional value is maintained.
The hydraulics are operated using an electro hydraulic system and just require a single set of flow and return valves.
As standard, the Grazer is carried on segmented double bogie axles to ensure even weight distribution and contour following. The axle is fitted with bronze greasable bushes for a long life. The largest GT160 can be fitted with a tri-axle system with rear steering.
Robust Build
To ensure a long working life, all the main carrier beams in the chassis and the main frame are fabricated using high grade 12mm wall box steel. The axle and main pivot point use 60mm solid pins that are supported on 20mm thick bushes with 4mm bronze greasable inserts.
The standard specification also includes an auto oiler and centralised greasing for ease of maintenance.
